Flame polishing machine PF

Range of PF flame polishers to achieve a clear and transparent finish on methacrylate. Polishing methacrylate with a blowtorch is the most comfortable, practical and effective. Thanks to the different models of PF flame polishers from BERMAQ you will find the perfect solution for your company.

These machines produce a high-temperature flame (1200-3300ºC) and high precision through an Oxygen and Hydrogen reaction thanks to the electrolysis of distilled water. This makes it a safe and clean solution. In addition, the finishes of the parts are smooth, shiny and of high-quality.

BERMAQ has several models such as the flame polishing machines PF and other flame polishers for micro-welding and flame polishing for acrylic parts.

Video

Technical Specifications


MODEL 500 MODEL 800 MODEL 1200
Gas production 75 lt/h 120 lt/h 240 lt/h
Distilled water use (per day) 30 ml 50 ml 100 ml
Max. temperature 3300ºc 3300ºc 3300ºc
Electrical usage 0.50 Kw 0.80 Kw 1.20 Kw
Flash back fitted Yes Yes Yes
Torch tips (range supplied) 20 – 24 18 – 24 17 -24
Torch tips (bore size supplied in mm) 0.60 – 0.31 0.90 – 0.31 1.00 – 0.31
Service recommended (in months) 12 12 12
Length x width x height (mm) 400 x 200 x 300 400 x 280 x 380 440 x 320 x 395
Weight 20 Kg 30 Kg 50 Kg

Applications

  • Flame polishing acrylic
  • Precision micro soldering
  • Precision micro welding
  • Internal flame polishing
  • Jewelry repairs
